| Brand Name : | Futao |
| Model Number : | FT-CP032 |
| Certification : | ISO 9001 |
| Price : | $80 - $1000 |
| Payment Terms : | L/C, T/T |
| Supply Ability : | 1200 pieces every month |
| Delivery Time : | 30 - 60 workdays |
Product Description
l Model Number: FT-CP022
l Design Standard: AASHTO (American Association of State Highway Transportation Officials) Standard
l Sensor Type: CMOS
l Power Consumption: 20w
l Pole Shaft Material: ASTM A572 GR65/Q345/Q235/GR50
l Brackets: Single or Double Brackets are available depending on security camera requirements
l Mounting Method: Base Plate mounting with anchor bolts/ Direct Burial
l Surface Treatment: Hot Dip Galvanization/ Powder Coating
l Aseismic Design: Built to withstand up to a Magnitude scale of 7 and below
l Color: RAL Color Standard
l Material: Q235, 355, A36, GR50,GR65
l Dimension Tolerances: +/-1%
l Pole Shape: Conical, Polygonal (Hexagonal, Octagonal,
Dodecagonal)
Specific Details
| Material | ASTM GR65,GR50,Q460 A572,S355,Q345/Q235 |
| Design Wind | 30M/S or depending on clients’ request |
| Poles Deflection | Accordance with the pole strength as Clients request. |
| Pole’s shape | Conical, Polygonal, Round |
| CCTV Poles Type | “T” Type,”L”Type,”I” Type |
| CCTV Pole Main Shaft Height | Normally, the Traffic Poles used to Cross Road. |
| CCTV Pole Cantilever Length | Depending on width of Road in Clients Country. |
| Application | Main Street,High Way Zones |
| Height | 1-16M composed of two or three sections |
| Pole Shaft Thickness | 2.5mm-20mm |
| Poles Stiffener Size | Accordance with Flange size to decide |
| Overlap Length Calculation | Upper Section of the bottom diameter more than 1.5 times |
| Surface treatment | Hot Dip Galvanization, Electrostatic Spray |
| Components | Signal Lights(Red/Green/Yellow Color),Camera etc. |
| Power Cabinet | Power Cabinet installed at outdoor to control the Signal Lights Colors Exchanged. |
| Power Cable Length Using | Power Cable Length using depending on the Poles height and Signal Lights/Camera Wattage/Quantity. |
| Galvanization Thickness | 80-100 microns on average according to BS EN ISO1461 standards |
| Galvanization Suitable Wall Thickness | At least ≥2.5mm Wall Thickness, |
| How long Dipped into Zinc pool for the poles | The time Dipped into Zinc pool depending on the poles Wall Thickness and the Galvanized thickness Execution Standard |
| Mounting Height | 6M,10M |
| Pole Shape | Conical, Polygonal, Round |
| Brackets | Single or Double Brackets of various sizes and shapes as per clients’ requirements |
| Welding | Welding conforms to international welding standard of CWB |
| Base Plate Mounting | A square or round Base Plate with slotted holes used in tandem with anchor bolts |
| Ground Mounting | The bottom part of the pole shall be buried underground at site. Depth of burial as per clients’ requirements |
| Galvanization | Hot Dip Galvanization with and average thickness of 80-100µm |
| Powder Coating | Pure Polyester Powder Painting, coloring optional |
| Joint Type(Connection method) | Slip joint by upper section insert into lower section |
| Flange connection to flange(outer flange/inner flange) | |
| Minimum yield strength | 355 Mpa |
| Minimum ultimate tensile strength | 490 Mpa |
| Max ultimate tensile strength | 620 Mpa |
| Length of per section | Within 14m once forming without slip joint |
| Welding | We has past flaw testing.Internal and external double welding makes
the welding beautiful in shape Welding Standard :AWS ( American Welding Society ) D 1.1 |
| Welds slags removing | Burrs or sharp edges shall be removed,all welds shall be cleaned mechanically against slag and spatters before hot dip galvanizing. |
Process of Production
Verification of Materials → Cutting → Molding or Bending → Vertical Welding → Verification of Dimensions → Flange Welding → Hole Drilling → Calibration → Deburring Process → Galvanizing, Powder Coating or Painting → Recalibration → Threading → Packaging
Product Details
Testing
Packaging & Shipping
We pack the top and bottom parts of the pole with a mat or straw
bale in order to protect it from damage to the galvanized surface
that may occur during transportation.
Packaging can also be done according to clients’ requirements.
We can ship the poles by sea or air or express or trains and we
have our regular shipping agent.
